KL-6300 FiberMASTER OTDR

KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR
KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR KL-6300 FiberMASTER OTDR
Core features
• Wide dynamic range 30-45dB • 7-inch color LCD touch screen • VNC/GPS/WIFI • Multi-trace analysis • F/P analytical judgment function • Smart map to analyze links graphically
Recommended Products
  • OLC-200 OTDR Launch Cable
  • KL-6200 Fiber Master OTDR
  • KL-360T Backbone Optical Fusion Splicer
  • FIP-600V Fiber Optic Connector Inspection System
  • OLS-22 Mini Multi-functional Optical Light Source
  • OPN-35 PON Power Meter
Features
  • 1.jpg
    KL-6300 FiberMASTER OTDR
    ● FiberMASTER OTDR
    ● 7-inch color LCD touch screen
    ● Wide dynamic range 30-45dB
    ● iOLA, one-click Intelligent testing of passive PON networks
    ● 0.8 m event dead zone
    ● VNC/GPS/WIFI
    ● Generate PDF reports quickly
    ● F/P analytical judgment function
    ● Smart map to analyze links graphically
  • 2.jpg
    iOLA (Hawkeye)
    iOLA (Hawkeye) is an OTDR-based application designed to simplify the OTDR testing process by eliminating the need to configure parameters, analyze and interpret multiple complex OTDR curves.
  • 3.jpg
    7.0 inch multi-touch capacitive touch screen
    It supports new gestures to amplification. The screen capture color is clear. The interface design is simple and clear.
  • 900.jpg
    Splitter Test
    Test three-level splitter, up to 1:128
  • 5.jpg
    Pass & Fail analysis function
    Automatically perform Pass/Fail judgments for each event based on pre-specified thresholds.The measurement results can be viewed through the result display items (As shown in the red box on the following side).
  • 6.jpg
    Smart map analyze links graphically
    With Smart Map, users only need to press one button to execute measurement, detect network events and execute Pass & Fail judgment.
  • 7.jpg
    Multi-trace analysis
    View multi -trace, can view up to 4 traces at the same time, comprehensive analysis, and the results are more accurate.
  • 8.jpg
    Bidirectional testing
    Averaging values obtained from opposite directions provides a more accurate quantification of losses. Bidirectional testing is a great way to improve test integrity in long-distance applications.
  • 9.jpg
    4-points testing
    Real-time monitoring of splicing and insertion loss, less noise impact, more accurate test results
  • 10.jpg
    Battery
    Battery working time: 12 hours(10500mAh)
  • 11.jpg
    Rubber sheath design: effective shock absorption, anti-fall and anti-bump
  • 12.jpg
    Not just OTDR
    ● OPM module: Used to measure absolute optical power orthe relative loss of optical power through a section of fiber link
    ● SLS module:Output stable continuous signal, used in combination with an OPM to measure optical loss in fiber optic systems
    ● VFL module:Luminous stability, strong light source, strong penetration; Two light source modes - steady on, flashing
    ● Network test module:Network sequencing + Network ranging + Network hunting (optional)
    ● Fiber connector inspection module: The fiber connector end-face inspection module can visualize the surface of the connector
  • 4.jpg
    Quickly generate the PDF report
    Built -in post -processing software to generate reports of PDF format.
  • 13.jpg
    GPS
    Real-time positioning OTDR position and running track
  • 14.jpg
    WIFI remote control
    VNC remote control function, using mobile phones or computers online remote operation OTDR easily solve the remote work, can simultaneously take into account multiple room testing, greatly improve efficiency
  • 15.jpg
    Self calibration
    Shorten maintenance time and reduce maintenance costs
  • 16.jpg
    Appearance
    Supports FC (standard)/SC (optional)/LC (optional) multiple adapters
OTDR module
ModelKL-6300-S1KL-6300-S2KL-6300-S3KL-6300-S4KL-6300-S5KL-6300-P1KL-6300-P2KL-6300-MKL-6300-MS
Wavelength(nm)1310/15501310/15501310/15501310/15501310/1550PON 1310/1550/1625 (built-in filter)850/1300850/1300+1310/1550
Dynamic range  (dB)32/3035/3340/3842/4045/4332/30/2838/36/3420/2220/22 32/30
Number of optical port111112212
Event dead zone★①  (m)0.80.80.80.80.8111.5SM≤1;MM≤1.5
Attenuation dead zone★②  (m)332.52.52.5335SM≤3.5;MM≤5
Multi-fiber Measurement
Multi-pulse Measurementx
Spliters MeasurementMax:32Max:64Max:128Max:32Max:64xMax:32
Applicable fiberSM (ITU-T G.652)
Distance range (km)0.1, 0.3, 0.5, 1.3, 2.5 , 5, 10 , 20 , 40 , 80   , 120 ,160 , 260, 320
Pulse width (ns) 3, 5 , 10 , 30 , 50 , 100 , 200 , 300 , 500,   1000 , 2500 , 5000, 10000 , 20000
Number of sampling pointsMax250000
Sampling resolutionMin 0.04m
Distance measurement accuracy±(0.75 m + Measurement distance × 2 × 10−5  + Sampling resolution)
Loss measurement accuracy±0.03 dB/dB
Return loss measurement accuracy±2 dB
Optical Power Meter Module (Built-in)
OPMWavelength800 ~ 1650nm
Measure range-70 ~ +6dBm
Measure accuracy<(±0.2dB   or ±5%
Display resolution0.01dB
Optical input port2.5mm Universal ferrule foSC,FC,ST
Stabilized Light Source Module(Built-in)
SLSWavelength(nm)1310/15501310/1550/1625850/1300850/1300+1310/1550
Output power-10dBm
Modulation modeCW,   270 Hz, 1 kHz, 2 kHz
Laser classClass   1M or Class 1
Optical input portOTDR port
Visual Fault Locator Module(Built-in)
VFLWavelength(nm)650±10nm
Output power10mW
Modulation modeCW, CHOP (2 Hz)
Laser classClass 3R
Optical input port2.5 mm Universal ferrule type forFC,SC,ST
Fiber Inspection Probe(Built-in)Optional
FIPPass / Fail
Magnification400X
Resolution(um)≥1.0
Electrical interfaceUSB2.0
Optical ConnectorFC/UPC,SC/UPC,ST/UPC
CMOS size1/3 inch
RJ45 Networks Test(Built-in)
RJ45Applicable cableCAT5, CAT6
Distance of Cable Collationl300m
Distance of emitting signal300m
GPS(Built-in)Optional
GPSLocation accuracy< 50m
Real-time Monitoringsupport
WIFI Module(Built-in)
WIFIData transmission
Remote Control
General Specifications
Link Map
Pass/Fail judgment
Distance unitm,   km, mile, kf
PC Analysis Software
LanguagesEnglish, Español, Chinese, Português, Français, Русский,ภาษาไทย,한국어
Optical connectorFC/UPC (SC/UPCLC/UPC Optional)
Display77-inch touch screen(Resolution:   1024 × 600)
PortCharge por x 2,  12V - 2.5A & Type C
Operating temperature-10 - 50˚C (0 - 40°C when AC adapter is being used, 0 to 35˚C  when battery is be charged)
Storage temperature-20 to 60˚C
Altitude4000 m
Humidity0 to 90% RH (20% -90% 739874  AC 适配器, 无霜
Power requirements100 - 240V AC, 50/60Hz (AC adapter,non-condensing)
Battery7.4V,10500mAh,≥77Wh
LED Light illumination >15000mcd
Operating time★③12小时
Data storageInternal storage: 10000 traces External storage : USB memory
Dimensions232   mm (W) × 161 mm (H) × 70 mm (D)
Weight1.6 kg (including internal battery and protectors, excluding OTDR unit and options)


Notes:

★①. Minimum pulse width, return loss: ≥55 dB (≥40 dB for 850/1300 nm), group refractive index: 1.5, the unsaturated peak level <1.5dB.

★②. Minimum pulse width, group refractive index: 1.5, the backscatter level is >0.5dB of the normal level. For SMF, at 1310nm, return loss: ≥55dB. For MMF, at 850nm, return loss: ≥40dB.

★③. New Battery All specifications valid at 23°C ± 2°C (73.4°F ± 3.6°F) unless otherwise specified.
