KL-360T Backbone Optical Fusion Splicer

KL-360T Backbone Optical Fusion Splicer KL-360T Backbone Optical Fusion Splicer KL-360T Backbone Optical Fusion Splicer KL-360T Backbone Optical Fusion Splicer
KL-360T Backbone Optical Fusion Splicer KL-360T Backbone Optical Fusion Splicer KL-360T Backbone Optical Fusion Splicer KL-360T Backbone Optical Fusion Splicer
Category: Fusion Splicer
Manual Catalogue Tutorials VR
Core features
● 5" 800x480 HD screen● Suitable for SM/MM/DS/NZDS/BIF single core fiber● 3-in-1 fiber holder ● X, Y, XY, X/Y : 320X Magnification● Average splicing loss: 0.01dB● Compact, light weight & faster● Fast-splicing 6s, fast-heating 16s● Electrodes life: 5000 times● The last 10,000 splice records and 2,000 result images● 5200mAh battery capacity, 300 times splice & heat cycles
Recommended Products
  • JL-ELE-N Electrodes for Fiber Fusion Splicer
  • 280E All-rounder Middle Trunk Line Fusion Splicer
  • 280T All-Rounder Middle Trunk Line Fusion Splicer
  • KL-21C High Precision Fiber Cleaver
  • KL-6200 Fiber Master OTDR
  • KL-23F High Precision Fiber Cleaver
  • FIP-600V Fiber Optic Connector Inspection System
KL-360T Backbone Optical Fusion Splicer
Category: Optical Fiber Fusion Splicer
RequestRequest a quote consultOnline consultation Telephone+54 1135692774
Features
  • KL-360T Backbone Optical Fusion Splicer
    Waterproof and dustproof
    ● Full body rubber sheath
    ● Adapt to various environments, anti-drop, waterproof, dustproof
  • Fast heating, fast welding
    Fast heating, fast welding
  • fusion splicer,Fully automatic welding heating
    Fully automatic welding heating
    ● 6S welding, let you work one step faster
    ● 16s heating, sustainable 215° heating
  • fusion splicer,Three in one fixture
    Three in one fixture
    ● Three-in-one multi-functional universal clamp
    ● The clamp is compatible with various types of optical fibers, saving time and effort in operation
  • fusion splicer Core Alignment
    Core Alignment
    ● Core alignment--5.0” inch high-definition LCD display
    ● Provide users with a large and clear optical fiber
    ● Core display image, splice loss, core alignment, at a glance
  • fusion splicer,double layer cooling tank
    double layer cooling tank
    ● Double-layer cooling tank--2 times more carrying capacity than conventional
Product Specification


Splice MethodCore Alignment
Applicable FibersSM(ITU-T G.652&G.657) / MM(ITU-T   G.651) / DS(ITU-T G.653) / NZDS(ITU-T G.655)
Compatible Fiber/Cable0.25~3.0 mm / indoor cable
Fiber HolderReplaceable (Universal: FH-60, SOC   Holder: FH-SOC(optional))
Fiber DiameterCladding: 80-150μm，Coating: 100~1000μm
Fiber Cleave Length8~16 mm
Splice modeMax 128 modes
Typical Splice LossSM: 0.02dB / MM: 0.01dB / DS: 0.04dB /   NZDS: 0.04dB / G.657: 0.02dB ★①
Return Loss>>60dB
Splicing TimeSM Quick mode : 6 sec / SM Average: 16   Sec.
Estimated Splice LossAvailable
Heating TimeQuick mode 16 sec.(SM G652 250μm 40mm   Sleeve) adjustable
Protection Sleeve Length20mm, 30mm, 40mm, 50mm, 60mm
Heat ProgramsMax 32 modes
Battery5200mAh Battery Capacity, Typical 300   Cycles (Splice&Heat) per Charge ★②
Electrode Life5000 arcs, can be extended by using an   electrode grinder ★③
Auto-startSplice / Heating
Automatic Fiber IdentificationSMF / MMF / other
Automatic ARC IdentificationAutomatic arc calibration by air pressure   and temperature
Results StorageThe last 10,000 splice records and 2,000   result images
Tension Test1.96~2.25N
Operating ConditionAltitude: 0~5000m, 0~95% relative   humidity, -20~50°C, Max Wind 15m/s
Storage Condition0~95% relative humidity, -20~60°C
Display5.0” color high resolution (800 x 480)   display
Fiber MagnificationX, Y, XY, X/Y : 320X Magnification
Power SupplyAC Input 100-240V, DC Input 9-14V
TerminalUSB2.0
Weight1.6kg without battery / 1.9kg with   battery
Size138H x 160W x 150D mm (including rubber   bumper)

★①  With identical fibres(in room temperature). Measured by cut-back method relevant to ITU-T and IEC standards.

★②  Splice & Heat cycles may vary depending on the battery status and the operating environment.

★③  Electrode life may vary depending on the operating environment.


Product manual
Products Tutorials
    No data
Product configuration
  • Fusion splicer
    Fusion splicer
  • all equipped
    all equipped
