OFI-45V Hi Precision Fiber Identifier

OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier
OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier OFI-45V Hi Precision Fiber Identifier
Category: Optical Fiber Identifier
Manual Catalogue Tutorials VR
Core features
● Comes with VFL function● Low power reminder.● Display relative optical power.● Test sensitivity -40dBm to 10dBm.● Test online without interruption of the link.● Recognize the signal of 270Hz,1KHZ,2KHz.● Comes with a hood to provide more accurate test results outdoors.● Identify the propagation direction of light,soundalarm reminder.● LED display,4 fixtures support bare fber,0.9mm,2mm, 3mm fiber.
Recommended Products
  • OFI-45P Optical Fiber Identifier
  • Optical Fiber ldentifier OFI-60V
  • Optical Fiber ldentifier OFI-60P
OFI-45V Hi Precision Fiber Identifier
Category: Optical Fiber Identifier
RequestRequest a quote consultOnline consultation Telephone+86 4008836695
Features
  • 8.jpg
    Fiber optic signal recognition instrument optical power all-in-one machine
    ● Metal body
    ● Easy to operate
    ● OPM function
  • 7.jpg
    OPM function
    ● Built-in optical power function
    ● High-precision high-quality detector, ±0.2dB accuracy
  • 6.jpg
    Universal for single-mode and multi-mode fibers
    ● Any position of single-mode and multi-mode fiber can be detected and detected online, and the response can be quickly
  • 5.jpg
    Comes with strong lighting
    ● With LED light function
    ● Can adapt to work in dark environment
  • 4.jpg
    Identify three signal frequencies and fiber orientation
    ● 270Hz / 1kHz / 2kHz
    ● Detect the fixed carrier signal loaded in the optical signal to identify a specific fiber
    ● Can identify 3 common signal frequencies, and there will be a buzzer sound when identifying
  • 2.jpg
    Online business testing without interruption
    ● To avoid line interruption caused by misoperation, put the pigtail into the test area, press the test trigger (switch), the clamp tightly clamps the optical fiber under test, and the instrument automatically starts the test
  • 1679990727155776.jpg
    Microbending Test Technology
    ● Accurately identify the direction of the fiber
    ● When the fiber has a signal, the left and right direction arrows show the signal direction, and the right direction light is on, indicating that the light source is from left to right
  • 1679990735803729.jpg
    Four fixtures
    ● Can measure four fiber types
    ● Applicable to 3.0/2.0/0.9/0.25mm fiber optic cable
Product Specifications


TypeOFI-45V
Identified wavelength range800-1700nm
ldentifed Signal TypeCW,270 Hz ± 5%,1 kHz ± 5%,2 kHz ± 5%
Detector Typeφ1mm InGaAs 2 pcs
Adapter Type$0.25(for Bare   Fiber),p0.9,$2.O(Applicable for o3.0Cable)
Signal DirectionLeft & Right LED
Optical Power Reading-40 dBm to 10 dBm
Signal Frequency270Hz,1kHz,2kHz
Power Supply6F22ND/6LR61
Operating Temperature-10°C to 60°C
Storage Temperature-25°C to 70°C
Dimension19.5*8*3cm
weight255g
VFL
Power range1mW
Testing distance3~5KM
Wavelength range650nm
Laser typeLD
Led flashlight支持
